Rolling Clothing Tag Variable Data Printig System

Customization:	Available
Type:	Demand for Ink Coding Machine
Usage:	Daily Industrial, Chemical Products, Drug, Food

Send Inquiry

Product Description

Basic Specifications

Model NO.

UV540

Automatic Grade

Automatic

Principle

Drop on Demand

Application

High Resolution Ink Jet Printer

Working Patterns

On-Line

Supplies

Ink

Packaging

Box

Joint Type

Multi Print Head Seamless Joint

Ink Solution

Support Porous, Semi-Porous and Non-Porous

Languages

English, Japanese, French, German, Spanish, Portuguese

Resolution

150-600dpi

Power

AC 90V-240V/50-60Hz

OEM

Accepted

Training

Free

HS Code

8443322100

Production Capacity

500 Sets/Year

Product Description

Rolling Clothing Tag Variable Data Printing System

Introduction

UV DOD inkjet system adopts industrial piezoelectric on-demand inkjet technology, has greatly improved in production speed and spray printing quality. Equipped with industrial high-resolution and high-speed DOD piezoelectric print heads, it meets the increasing and rigorous demands for applications of mailings, barcodes, bills, checks, packages, and marking. It is suitable for web printing, sheet-fed, and both online and offline target printing. Its modular design allows easy integration into existing transport systems.

Technical Details

Equipment: UVJET
Nozzle type: Ricoh GEN5/Kyocera108 or Konica 1024i industrial piezoelectric nozzle
Nozzle lifespan: more than 3 years, 10 billion printing times
Single Nozzle print width: 54/72/108 mm (based on requirements)
Printing unit: 1 ~ 24 groups can be extended, seamless joint
DPI: Physics 600 dpi printing precision
Linear speed: 70 ~ 180 m/min
Inks: Imported environmentally friendly UV or water-based inks
Substrates: Suitable for paper, plastics, PVC/PP/PE film, etc.

Our Software Solutions

Printer Control Software (PCS) provides a user-friendly interface to control the printer, monitor status, and set options like jetting waveforms and temperature for each print head. Features include database checking, DPI settings, motor speed settings, and more.

Variable Data Printing Software supports various objects: text, dates, times, graphics, logos, serial numbers, barcodes, and database photo images. It supports data sources like .CSV, .XLS, .XLSX, .TXT, and PDF files.

Print Head Specifications

Model	VDG540/VDK720/KY108	Print Head	Ricoh GN5/Konica 1024i/KY
Head Origin	Japan	Resolution	600×600, 400, 300, 200 dpi
Single head width	54.0mm/72.0mm/108mm	Printing Speed	180m/min (600×200dpi) 75m/min (600×600dpi)
Max. Width	54/72/108mm×24 Seamless Joint	Method	Piezoelectric ink-jet
Structure	Online Printing	Drop Size	5-21PL
System	Windows 7	Port	Gigabit Ethernet
Barcodes	UPCA, EAN13, CODE128, QR, DATAMATRIX, etc.	Formats	MS Excel, TXT, PDF, BMP

Frequently Asked Questions

What materials can this system print on?

The system is highly versatile and suitable for all kinds of paper, plastics, and various films including PVC, PP, and PE.

What is the maximum printing speed?

The equipment can reach a linear speed of up to 180 m/min at a resolution of 600×200dpi.

What type of ink does the system use?

It uses imported environmentally friendly UV inks or water-based inks depending on your specific printing requirements.

Does the software support variable data?

Yes, the software supports variable data printing for text, dates, serial numbers, barcodes, and database-linked images from CSV, Excel, and PDF files.

How many languages are supported by the interface?

The system supports multiple languages including English, Japanese, French, German, Spanish, Portuguese, Russian, and Chinese.

What is the expected lifespan of the print heads?

Under normal operating conditions, the industrial piezoelectric nozzles have a lifespan of more than 3 years or approximately 10 billion printing times.
