Our latest UV Drop-on-Demand (DOD) technology offers proven performance, flexible resolutions, and modular expandability. This UV inkjet system is designed to integrate seamlessly onto presses, rewinders, or cut-sheet vacuum transports. It is ideal for printing on challenging substrates such as films, foils, plastics, coated stocks, and various synthetics.
| Functionality | Details |
| Core Components | High-speed digital inkjet system, UVLED curing, negative pressure ink supply. |
| Material Compatibility | Films, labels, metals, and various synthetic packaging materials. |
| Nozzle Technology | Japan-imported industrial piezoelectric nozzles (G5) for high precision. |
| Ink Performance | Environmentally friendly black LED UV ink for stable, non-stop production. |
| Online Detection | Optional industrial vision system for real-time QR/Barcode verification. |
| Printing Speed | Standard 70-180 m/min stable operating range. |
| Data Safety | Independently developed platform ensuring secure and flexible variable data handling. |
Software Excellence:
Hardware Reliability:
A: The system supports high-precision printing ranging from 150 dpi up to 600 dpi, depending on your specific speed and quality requirements.
A: It is designed for difficult substrates including films, foils, plastics, metals, and coated stocks used in the pharmaceutical and packaging industries.
A: The printing speed can reach up to 180 m/min. At a high resolution of 600 x 600 dpi, it maintains a stable speed of 75 m/min.
A: Yes, the software platform is specifically designed for high-speed variable data printing, including QR codes, barcodes, anti-counterfeit codes, and logos.
A: It is compatible with both UV curable inks and water-based inks. The system includes a UVLED curing group for rapid drying on non-porous surfaces.
A: Yes, the 54mm nozzles can be freely combined and seamlessly spliced to achieve wider printing breadths based on your specific requirements.
